| Projector type | LCD projectors |
|---|
| Display method | Transparent LCD panel (x 3, R/G/B) |
|---|
| Display Device -> Panel size | 16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
|---|
| Display Device -> Drive method | Active matrix method |
|---|
| Display Device -> Number of pixels | 2,304,000 (1920 x 1200) pixels |
|---|
| Light source | Laser diodes |
|---|
| Light output | 5,200 lm |
|---|
| Light output (ANSI) | 5,200 lm |
|---|
| Time until light output declines to 50 % -> NORMAL | 20,000 hours [NORMAL] |
|---|
| Time until light output declines to 50 % -> ECO | 24,000 hours [ECO] |
|---|
| Time until light output declines to 50 % -> QUIET | 20,000 hours [QUIET] |
|---|
| Résolution | WUXGA (1920 x 1200 pixels) |
|---|
| Contrast Ratio (typ.) | 3,000,000:1 (Full On/Full Off)
(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
|---|
| Screen size (diagonal) | 0.76–7.62 m (30–300 in), 16:10 aspect ratio |
|---|
| Center-to-corner zone ratio | 85% |
|---|
| Lens | 1.6x manual zoom (throw ratio: 1.09–1.77:1), manual focus lens, F 1.60–2.12, f 15.30–24.64 mm |
|---|
| Digital Zoom Extender *5 | Throw Ratio 1.09–2.21:1*5 (Corresponding value. When used together with optical zoom.) |
|---|
| Lens shift -> Vertical(from center of screen) | +44 % |
|---|
| Lens shift -> Horizontal(from center of screen) | ±20 % |
|---|
| Keystone correction range | Vertical: ±25 °, Horizontal: ±35 ° |
|---|
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
|---|
| Terminals -> HDMI™ IN | HDMITMTM 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p*6 signal input), CEC supported*7 |
|---|
| Terminals -> COMPUTER IN（D-SUB 15pin） | D-sub 15-pin (female) x 2(RGB/YPBPR/YCBCR) |
|---|
| Terminals -> AUDIO IN(M3 Stereo Mini Jack) | M3 stereo mini-jack x 2 |
|---|
| Terminals -> AUDIO OUT(M3 Stereo Mini Jack) | M3 stereo mini-jack x 1 |
|---|
| Terminals -> SERIAL IN | D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
|---|
| Terminals -> DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control)
(HDBaseTTM compliant), 100Base-TX (Compatible with PJLinkTM [Class 2],
HDCP, Deep Color, 4K/30p*6 signal input) |
|---|
| Terminals -> LAN | RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLinkTM [Class 2] |
|---|
| Terminals -> USB TYPE A | USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module,
power supply (DC 5 V, maximum 2 A*8) |
|---|
| Protocol versions | IPv4, IPv6*9 |
|---|
| Power supply | AC 100 V–240 V, 50/60 Hz |
|---|
| Maximum power consumption | 305 W (3.1–1.3 A) (310 VA)
(Power consumption is 295 W at 200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Normal | [NORMAL]
270 W (100–120 V),
255 W (200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Eco | [ECO]
195 W (100–120 V),
185 W (200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Quiet | [QUIET]
190 W (100–120 V),
180 W (200–240 V) |
|---|
| Built-in speaker | 10 W monaural |
|---|
| Cabinet materials | Molded plastic |
|---|
| Filtre | Included |
|---|
| Estimated filter maintenance cycle | Approx. 20,000 hours |
|---|
| Operation noise -> Normal | 36 dB [NORMAL] |
|---|
| Operation noise -> Eco | 36 dB [ECO] |
|---|
| Operation noise -> Quiet | 26 dB [QUIET] |
|---|
| Dimensions (W x H x D) | 399 mm x 115 mm x 348 mm (15 23/32˝ x 4 17/32˝ x 13 11/16˝ ) (not including protruding parts)
399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (with feet at shortest position) |
|---|
| Dimensions (W x H x D) -> Width (not including protruding parts) | 399 mm (15 23/32˝) |
|---|
| Dimensions -> Width (including protruding parts) | 399 mm (15 23/32˝) |
|---|
| Dimensions -> Height (not including protruding parts) | 115 mm (4 17/32˝) |
|---|
| Dimensions -> Height (including protruding parts) | 133 mm (5 1/4˝ ) |
|---|
| Dimensions -> Depth (not including protruding parts) | 348 mm (13 11/16˝) |
|---|
| Dimensions -> Depth (including lens) | 348 mm (13 11/16˝) |
|---|
| Weight | Approx. 6.5 kg (14.33 lbs) |
|---|
| Operating environment -> Operating temperature | 0–45 °C (32–113 °F) |
|---|
| Operating Environment -> Operating humidity (No condensation) | 20–80 % (no condensation) |
|---|
| Applicable software | Multi Monitoring & Control Software, Logo Transfer Software, Presenter Light Software for Windows®*15, Wireless Projector App for iOS/AndroidTM*16 |
|---|
| Footnote Description | - When [PICTURE MODE] is set to [DYNAMIC], [LIGHT POWER] is set to [NORMAL], [DAYLIGHT VIEW] is set to [OFF], and [AUTO POWER SAVE] is set to [OFF].
- Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.
- Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.
- Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter). Estimated time until light output declines to 50 % varies depending on environment.
- Resolution decreases when using this function. 6-Point Screen Correction, V/H Keystone Correction, and curved-screen correction are not available when using this function, and range of corner adjustment is limited.
- When Digital Zoom Extender is set to 80%.
- 4K signals are converted to the projector's resolution upon projection.
- Depending on the connected CEC command compatible device, the link control may not operate normally.
- On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready.
- Requires projector firmware Ver. 2.00 or higher. The optional AJ-WM50 Series Wireless Module does not support IPv6.
- Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft).
- Filter cleaning cycle varies depending on the environment. The filter can be washed and reused up to two times. Filter cleaning cycle: 20,000 hours (under dust conditions of 0.08 mg/m3), 10,000 hours (under dust conditions of 0.15 mg/m3).
- Average value. May differ depending on the actual unit.
- Light output is limited at operating temperatures higher than 30 °C (86 °F), and projectors cannot be operated at altitudes higher than 2,700 m (8,858 ft) above sea level.
- When the optional AJ-WM50 Series Wireless Module is attached, the operating temperature range becomes 0–40 °C (32–104 °F).
- When using Presenter Light Software, images are projected with 1280 x 800 dots or 1024 x 768 dots onto the screen. Also, your PC display resolution may be forcibly changed, and audio playback disrupted or become noisy while images and sound are being transmitted.
- When using the Wireless Projector app, display resolution differs depending on your iOS/Android™ device and the display device. The maximum supported display resolution is WXGA (1280 x 800).
|
|---|
