1-Chip DLP™ Projectors PT-REQ12 Series

PT-REQ80

Expand Production Possibilities and Revolutionize Workflow with Next-Generation 1-Chip DLP™ 4K Projectors

Voir les spécifications complètes Partager la page

Principales caractéristiques

Dramatic Visuals Take Your Production to New Heights

Effortless Workflow, Improved Expandability

New Cabinet Design for Reliable Operation

TYPE DE VIDÉOPROJECTEUR	SÉRIE PT-REQ
MODÈLES	PT-REQ12	PT-REQ10	PT-REQ80
RÉSOLUTION	4K (3840 x 2400)³	4K (3840 x 2400)³	4K (3840 x 2400)³
LUMINOSITÉ	12 000 lm²	10 000 lm²	8 000 lm²

Livré avec objectif ET-C1S600 inclus.

Exploitez toute la puissance de visuels ultra dynamiques !

Les vidéoprojecteurs de la série REQ sont parmi les premiers projecteurs mono DLP™ à être dotés du Quad Pixel Drive, notre technologie de quadruplement des pixels à 2 axes, pour créer des images 4K profondes, fluides et détaillées. Les REQ prennent en charge des fréquences d’images de 240 Hz/1080p⁴ et fonctionnent avec notre système de suivi en temps réel de projection-mapping (en option). La nouvelle version de Dynamic Contrast inclut une analyse image-scène qui permet une reconnaissance plus détaillée des zones claires et sombres et une meilleure expression du contraste qui donne vie à vos images.

Galerie produits

Téléchargement

The next-generation PT-REQ80 1-Chip DLP™ 4K Laser Projector is designed to streamline productions and expand the endless possibilities of entertainment by delivering exceptional, highly engaging immersive experiences with up to 8,000lm brightness, 4K resolution, and 240 Hz projection capability.

Tableau des spécifications

Projector type	1-Chip DLP™ projectors
DLP™ Chip \| Panel Size	0.8 in diagonal (16:10 aspect ratio)
DLP™ chip \| Number of Pixels	2,304,000 (1920 x 1200 pixels)
Light Source	Laser diode
Light Output1 2	8,000 lm / 8,200 lm (Center)*3
Screen Size (Diagonal)	70–700 inches (with supplied lens)
Résolution	4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)
Contrast Ratio*1	25,000:1 (Full On/Full Off, Dynamic Contrast [3])
Time until light output declines to 50 %*4	20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)
Center-to-corner zone ratio*1	90 %
Lens	PT-REQ12/REQ10/REQ80: Powered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus; PT-REQ12L/REQ10L/REQ80L: Optional powered zoom/focus lenses

Voir les spécifications complètes

Série produits

PT-REQ12 Series

Accessoires & Logiciels

Metadata Handling

AJ-WM50

L'AJ-WM50 est un module compact bi-bande sans fil pour les caméscopes des gammes P2HD et AG-DVX200

PT-REQ12 Series
Model	PT-REQ12	PT-REQ10	PT-REQ80
Projector Type	1-Chip DLP™ projectors	1-Chip DLP™ projectors	1-Chip DLP™ projectors
DLP™ Chip \| Panel Size	0.8 in diagonal (16:10 aspect ratio)	0.8 in diagonal (16:10 aspect ratio)	0.8 in diagonal (16:10 aspect ratio)
DLP™ Chip \| Number of Pixels	2,304,000 (1920 x 1200 pixels)	2,304,000 (1920 x 1200 pixels)	2,304,000 (1920 x 1200 pixels)
Brightness	12,000 lm / 12,400 lm (Center)*3	10,000 lm / 10,300 lm (Center)*3	8,000 lm / 8,200 lm (Center)*3
Light Source	Laser diode	Laser diode	Laser diode
Time until light output declines to 50 %	20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)	20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)	20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)
Resolution	4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)	4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)	4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)
Contrast Ratio	25,000:1 (Full On/Full O, Dynamic Contrast [3])	25,000:1 (Full On/Full O, Dynamic Contrast [3])	25,000:1 (Full On/Full Off, Dynamic Contrast [3])
Screen Size	70–700 inches (with supplied lens)	70–700 inches (with supplied lens)	70–700 inches (with supplied lens)
Center-to-corner zone ratio	90 %	90 %	90 %
Lens	PT-REQ12/REQ10/REQ80: Powered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus; PT-REQ12L/REQ10L/REQ80L: Optional powered zoom/focus lenses	PT-REQ12/REQ10/REQ80: Powered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus; PT-REQ12L/REQ10L/REQ80L: Optional powered zoom/focus lenses	PT-REQ12/REQ10/REQ80: Powered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus; PT-REQ12L/REQ10L/REQ80L: Optional powered zoom/focus lenses
Lens shift \| Horizontal(From the origin point of the lens mounter)	±29 % (with ET-C1W400/W500/S600/T700), ±23 % (with ET-C1W300/U100)	±29 % (with ET-C1W400/W500/S600/T700), ±23 % (with ET-C1W300/U100)	±29 % (with ET-C1W400/W500/S600/T700), ±23 % (with ET-C1W300/U100)
Lens shift \| Vertical(From the origin point of the lens mounter)	±60 % (with ET-C1W400/W500/S600/T700), ±50 % (with ET-C1W300/U100)	±60 % (with ET-C1W400/W500/S600/T700), ±50 % (with ET-C1W300/U100)	±60 % (with ET-C1W400/W500/S600/T700), ±50 % (with ET-C1W300/U100)
Terminals \| HDMI 1/2 IN	HDMI™ x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)	HDMI™ x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)	HDMI™ x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)
Terminals \| DisplayPort	DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)	DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)	DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input)
Terminals \| Multi Sync In	BNC x 1	BNC x 1	BNC x 1
Terminals \| Multi Sync Out	BNC x 1	BNC x 1	BNC x 1
Terminals \| Serial In	D-sub 9-pin (female) x 1 for external control (RS-232C compliant)	D-sub 9-pin (female) x 1 for external control (RS-232C compliant)	D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
Terminals \| Serial Out		D-sub 9-pin (male) x 1 for link control (RS-232C compliant)	D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
Terminals \| Remote 1 In	M3 stereo mini-jack x 1 for wired remote control	M3 stereo mini-jack x 1 for wired remote control	M3 stereo mini-jack x 1 for wired remote control
Terminals \| Remote 1 Out	M3 stereo mini-jack x 1 for link control (for wired remote control)	M3 stereo mini-jack x 1 for link control (for wired remote control)	M3 stereo mini-jack x 1 for link control (for wired remote control)
Terminals \| Remote 2 In	D-sub 9-pin (female) x 1 for external control (parallel)	D-sub 9-pin (female) x 1 for external control (parallel)	D-sub 9-pin (female) x 1 for external control (parallel)
Terminals \| LAN	RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible	RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible	RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible
Terminals \| USB	USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module/USB memory	USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module/USB memory	USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module/USB memory
Terminals \| DC Out	USB Type A x 1 (for power supply, DC 5 V, 2 A)	USB Type A x 1 (for power supply, DC 5 V, 2 A)	USB Type A x 1 (for power supply, DC 5 V, 2 A)
Terminals \| Expansion Slot	Open slot for for function boards, Intel® SDM compatible	Open slot for for function boards, Intel® SDM compatible	Open slot for for function boards, Intel® SDM compatible
Protocol versions	IPv4, IPv6*5	IPv4, IPv6*5	IPv4, IPv6*5
Power Supply	AC 100–240 V, 50/60 Hz	AC 100–240 V, 50/60 Hz	AC 100–240 V, 50/60 Hz
Power consumption \| Maximum power consumption	1,030 W (10.4–4.3 A) (1,040 VA) (Power consumption is 990 W at AC 200–240 V)	870 W (8.8–3.7 A) (880 VA) (Power consumption is 840 W at AC 200–240 V)	760 W (7.7–3.2 A) (770 VA) (Power consumption is 730 W at AC 200–240 V)
Protocol versions	IPv4, IPv6*5	IPv4, IPv6*5	IPv4, IPv6*5
Operation Noise	38 dB (NORMAL/ECO), 35 dB (QUIET)	36 dB (NORMAL/ECO), 33 dB (QUIET)	35 dB (NORMAL/ECO), 32 dB (QUIET)
Operating Environment	Operating temperature: 0–45 °C (32–113 °F)*8, operating humidity: 10–80 % (no condensation)	Operating temperature: 0–45 °C (32–113 °F)*8, operating humidity: 10–80 % (no condensation)	Operating temperature: 0–45 °C (32–113 °F)*8, operating humidity: 10–80 % (no condensation)
Dimensions	PT-REQ12/REQ10/REQ80: 498 x 212 x 648 mm (25 1/2˝ x 8 11/32˝ x 21 3/16˝) (With feet at shortest position) PT-REQ12L/REQ10L/REQ80L: 498 x 212 x 538 mm (19 5/8˝ x 8 11/32˝ x 21 3/16˝ ) (With feet at shortest position)	PT-REQ12/REQ10/REQ80: 498 x 212 x 648 mm (25 1/2˝ x 8 11/32˝ x 21 3/16˝) (With feet at shortest position) PT-REQ12L/REQ10L/REQ80L: 498 x 212 x 538 mm (19 5/8˝ x 8 11/32˝ x 21 3/16˝ ) (With feet at shortest position)	PT-REQ12/REQ10/REQ80: 498 x 212 x 648 mm (25 1/2˝ x 8 11/32˝ x 21 3/16˝) (With feet at shortest position)PT-REQ12L/REQ10L/REQ80L: 498 x 212 x 538 mm (19 5/8˝ x 8 11/32˝ x 21 3/16˝ ) (With feet at shortest position)
Weight	PT-REQ12/REQ10/REQ80: Approx. 28.7 kg (63.28 lbs) (with supplied lens), PT-REQ12L/REQ10L/REQ80L: Approx. 27.0 kg (59.53 lbs) (without lens)	PT-REQ12/REQ10/REQ80: Approx. 28.7 kg (63.28 lbs) (with supplied lens), PT-REQ12L/REQ10L/REQ80L: Approx. 27.0 kg (59.53 lbs) (without lens)	PT-REQ12/REQ10/REQ80: Approx. 28.7 kg (63.28 lbs) (with supplied lens), PT-REQ12L/REQ10L/REQ80L: Approx. 27.0 kg (59.53 lbs) (without lens)
Control function via LAN	Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2)	Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2)	Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2)
Applicable software/application	Logo Transfer Software, Multi Monitoring & Control Software, Projector Network Setup Software, Real-Time Tracking Projection-Mapping System, Early Warning Software, Geometry Manager Pro, Smart Projector Control for iOS/Android™	Logo Transfer Software, Multi Monitoring & Control Software, Projector Network Setup Software, Real-Time Tracking Projection-Mapping System,Early Warning Software, Geometry Manager Pro, Smart Projector Control for iOS/Android™	Logo Transfer Software, Multi Monitoring & Control Software, Projector Network Setup Software, Real-Time Tracking Projection-Mapping System,Early Warning Software, Geometry Manager Pro, Smart Projector Control for iOS/Android™

Key Features
Taille compacte, s'intègre au boîtier de la caméra comme le WM30.
Bi-bande 2,4 GHz et 5 GHz (IEEE802.11 conforme a/b/g/n/ac)
Haute sécurité grâce au cryptage WPA2-PSK (TKIP/AES), WPA-PSK (TKIP/AES) et WEP (64 bit/128 bit)

Key Features
Taille compacte, s'intègre au boîtier de la caméra comme le WM30.
Bi-bande 2,4 GHz et 5 GHz (IEEE802.11 conforme a/b/g/n/ac)
Haute sécurité grâce au cryptage WPA2-PSK (TKIP/AES), WPA-PSK (TKIP/AES) et WEP (64 bit/128 bit)

Key Features
Possibilité de surveiller à distance jusqu'à 2 048 appareils à partir d'un navigateur Web sur PC ou tablette.
Préavis de maintenance
Détection préventive des pannes
Réaction rapide en cas de problème
Prend note des conditions de fonctionnement de chaque appareil et, selon le nombre d'heures qu'ils ont passé en fonctionnement, peut prédire la date de remplacement des consommables, celle des entretiens et nettoyages périodiques requis et, le cas échéant, les pièces non consommables à remplacer.

Key Features
Possibilité de surveiller à distance jusqu'à 2 048 appareils à partir d'un navigateur Web sur PC ou tablette.
Préavis de maintenance
Détection préventive des pannes
Réaction rapide en cas de problème
Prend note des conditions de fonctionnement de chaque appareil et, selon le nombre d'heures qu'ils ont passé en fonctionnement, peut prédire la date de remplacement des consommables, celle des entretiens et nettoyages périodiques requis et, le cas échéant, les pièces non consommables à remplacer.
