Short Throw Fixed-Focus Lens

ET-D3LEU100

Zero Offset Ultra Short Throw Fixed-Focus Lens

Deliver Spectacular Images at Short Distance with New Zero-Offset Lenses

Minimize Throw Distance, Increase Flexibility

Project in tight spaces from very short throw-distances. With zero offset capability, these two lens options widen the versatility of Panasonic’s 3-Chip DLP™ lineup.

^{*Value is for ceiling installations using the PT-RQ22K. Lens-shift value will vary by model. Please see the Throw Distance Calculator for more information. For floor installations, up and right shift will be defined as a positive value. Down and left shift will be defined as a negative value.}
^{Note: Graphic represents a 300-inch projection using the PT-RQ22K.}

Throw Distance Calculator

Wide-Range Adjustment After Projector Installation

Powered Vertical and Horizontal lens-shift provides wide-range adjustment after projector installation, saving time and effort. ET-D3LEW200 further enhances flexibility with powered optical zoom.

Lens Design Delivers an Unobstructed View

L-shaped design gives the audience a clear and unobstructed view of the image even in low-ceiling installations.

Other Features

Supports AFO (Active Focus Optimizer) to maintain the optimum focus-level regardless of content brightness
Compatible projectors continuously monitor ambient temperature around the lens and maintain optimum focus for sharp images, even immediately after start-up*
^{* With a firmware update available from February 2020 for the following compatible projectors: RQ32K/RZ31K/RS30K, RQ22K/RZ21K/RS20K.}

Product gallery

Specifications table

Lens type	Ultra-Short-Throw Lens
F Value	2.5
Focal Length	(f) 8.0 mm (5/16˝)
Screen Size	200-600 inches
Throw ratio \| 4K+	0.397:1
Throw ratio \| WUXGA	0.370:1
Throw ratio \| SXGA+	0.401:1
Lens-shift*1 \| Vertical	±59 %

View full specifications
