PressIT Wireless Presentation System

PressIt - Wireless Presentation System

Simple plug & play collaboration solution

Scroll down

Key features

For video and audio signals from PCs, iOS/Android, and other mobile devices
Two types of receivers: Set top box compatible with all displays and projectors, SDM board for SQ1 and SQE1 displays
Compatible with HDMI-CEC command control, linked operation with CEC compatible devices
Up to 4 simultaneous display sources, and up to 32 Transmitter simultaneous connections
No need for software and driver installation or network connection

3 Steps to Set Up PressIT

PressIT eliminates troublesome setups and cluttered cables. You only have to connect your receiver, connect your device and just PressIT.
There is no special software installation* necessary for your device. The presenter's device can be switched by simple click of a button, with no need to reconnect the cable.
* except dedicated app for Android devices

Further Product Specifications

 Basic setReceiver (Board)Transmitter (HDMI/USB)Transmitter (USB-C)
Model No.TY-WPS1TY-WPSC1TY-SB01WPTY-WP2B1TY-WPB1TY-WP2BC1TY-WPBC1
Product detailsReceiver (Box) x 1Receiver
(Box)x 1
Receiver (Board)x 1Transmitter (HDMI/USB) x 2Transmitter (HDMI/USB) x 1Transmitter (USB-C) x 2Transmitter (USB-C) x 1
Transmitter (HDMI/USB) x 2Transmitter (USB-C) x 2 Transmitter case x 1 Transmitter case x 1
Transmitter case x 1Transmitter case x 1

Specifications table

ProductWireless Presentation System Basic Set
Max. output resolution / FramerateReceiver : 1920 x 1080/60p,3840 x 2160/30p (max.)
Max. input resolution / FramerateTransmitter : 1920 x 1080/60p (max.)
Number of simultaneous connections32
Number of sources simultaneous on screen4
Data Rate | Wired10/100/1000 (Mbps)
Data Rate | WirelessReceiver : 867 Mbps (max.) Transmitter : 433 Mbps (max.)
Frequency Band5 GHz (5180 MHz to 5240 MHz)
