1-Chip DLP™ Projectors PT-RQ7 Series

PT-RQ7L

Immersive for all : Compact and Light 1DLP 4K Projectors

View full specifications Share page

Key features

Seamless Visuals, Endless Possibilities

Compact & Expandable for Easy Installation

Eco-Friendly Innovation with Proven Reliability

PT-RQ7 Series
Model	PT-RQ7L	PT-RQ6L	PT-RZ7L	PT-RZ6L
Light Output	7,500 lm ¹¹	6,500 lm ¹¹	7,500 lm ¹¹	6,500 lm ¹¹
Resolution	4K (3840 x 2160 pixels)¹	4K (3840 x 2160 pixels)¹	WUXGA (1920 x 1200 pixels)	WUXGA (1920 x 1200 pixels)

Making lmmersive 4K Visuals Accessible

Positioned between the FRQ60 Series and the REQ12 Series, the RQ7 Series expands our 4K projector offerings to give integrators more choice. Experience smooth 4K¹ visuals courtesy of Quad Pixel Drive² with rich color and minimal blur. Project 240 Hz/1080p content³ and fuse digital and analog elements seamlessly with our Real-Time Tracking Projection-Mapping System⁴. Improved Dynamic Contrast boosts visual impact, while a new Museum Mode further optimizes image quality.

Compact Design for an Effortless Workflow

Weighing just 18 kg (39.7 lbs) and about 29 % smaller than the existing RZ790/RZ690 models, the RQ7 Series reduces the logistical burden and your carbon footprint. Optional Intel® SDM standard SLOT-compatible function boards⁵, including Panasonic’s new ET-SBFMP10 media processor board⁶, adapts, scales, and expands projector connectivity. Save time with preactivated Geo Pro⁷ upgrade kits and use your existing Panasonic DLE Series lenses.

Stable, Reliable, and Efficient Projection

Project sustainably with lasting picture quality. The energy-efficient optical engine and laser light source module conform to the IP5X Dust Protected (IEC 60529) standard⁸, while a filterless design reduces waste and enables maintenance-free operation for 20,000 hours⁹. Multi-Laser Drive Engine and Backup Input¹⁰ maintain image display in the event of trouble, securing a repeatable guest experience.

^{1 PT-RQ7L/RQ6L only. Maximum physical resolution of 4K (3840 x 2160) with Quad Pixel Drive [ON].}
^{2 PT-RQ7L/RQ6L only.}
^{3 PT-RQ7L/RQ6L only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate.}
^{4 PT-RQ7L/RQ6L only. Optional ET-SWR10 is used in conjunction with third-party devices (sold separately). Compatibility with third-party devices cannot be guaranteed. Other conditions apply.}
^{5 Optional proprietary and third-party Intel® SDM standard SLOT-compatible function boards sold separately. Panasonic cannot guarantee the operation of third-party devices.}
^{6 Scheduled for release CY2024 Q4.}
^{7 Visit PASS to register your projector and download free Geometry Manager Pro software for Windows® (upgrade kits included).}
^{8 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.}
^{9 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, [NORMAL] Mode, [PICTURE MODE] set to [DYNAMIC], Dynamic Contrast [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.}
^{10 Terminal assignment is fixed. Signals to primary and backup must be identical.}
^{11 When ET-DLE170 is attached. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.}
^{12 Input signals to the PT-RZ7L/RZ6L are converted to the projector’s display resolution upon playback. YPBPR 4:2:0 format only for 4K/60p and 4K/50p signals input via DIGITAL LINK.}

Specifications table

Projector type	1-Chip DLP™ projector
DLP™ Chip \| Panel Size	16.5 mm (0.65 in) diagonal (16:9 aspect ratio)
DLP™ chip \| Number of Pixels	2,073,600 (1920 x 1080 pixels)
Light Source	Laser diodes
Resolution	4K (3840 x 2160 pixels) (Quad Pixel Drive: ON)
Contrast Ratio*2	15,000:1 (Full On/Full Off, Dynamic Contrast [3])
Screen Size (Diagonal)	1.27–5.08 m (50–200 in) with ET-DLE055, 1.27–15.24 m (50–600 in) with ET-DLE060/ET-DLE085/ET-DLE105/ET-DLE150/ET-DLE170/ET-DLE250/ET-DLE350/ ET-DLE450, 2.54–8.89 m (100–350 in) with ET-DLE035, 2.54–10.16 m (100–400 in) with ET-DLE020G/ET-DLE020

View full specifications

Accessories & Software

Brackets

ET-PKD120H

High ceiling mount bracket

View product

Brackets

ET-PKD120S

Low ceiling mount bracket

View product

Brackets

ET-PKD130H

View product

Showing 3 of 3

APantac SDM - compatible with Panasonic

SDM board

TY-SDVoE-SDM

SDVoE Receiver for SDM

View product

Key Features
SDVoE receiver for SDM-S
Supports HDMI 2.0/HDCP 2.2/1.4
Supports UHD RGB/4:4:4 8 bit, 4:2:0 10 bit and 12 bit HDR
Supports all resolutions up to 594 MHz
Supports HDR pass through

Apantac SDM - compatible with Panasonic

SDM board

TY-SDI-HDTV-SDM

12G SDI Receiver for SDM

View product

Key Features
UHD SDI receiver for SDM-S
Supports 12G/6G/3G/HD-SDI input
SDI loop out
Output follows Input on Rec 709/2020
9.5W maximum power consumption

Apantac SDM - compatible with Panasonic

SDM board

TY-HDBT-SDM

UHD HDBaseT Receiver for SDM-S and SDM-L

View product

Key Features
UHD HDBaseT receiver for SDM-S
Comes with adapter for SDM-L
Supports HDMI 2.0/HDCP 2.2
Extends HDMI signal (1080P@12 bit) up to 330 feet (100 meters)
Extends HDMI (UHD@4:4:4) signals up to 230 feet (70 meters)

SDM board

TY-SB01FB

12G-SDI Optical Function Board

View product

Showing 4 of 5

Lenses for 1-Chip DLP

ET-DLE060

0.600-0.801:1 (WUXGA) Throw Ratio

View product

Showing 1 of 1

AVAILABLE FROM CY2024 Q4

Media Processor

ET-SBFMP10

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Media Processor

ET-FMP20

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Media Processor

ET-FMP50

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Showing 3 of 3

AVAILABLE FROM CY2024 Q4

Media Processor

ET-SBFMP10

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Media Processor

ET-FMP20

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Media Processor

ET-FMP50

Media Processors Simplify Multi-Projection Workflows for Immersive Experiences

View product

Key Features
Flexible Design Streamlines Installation
Simple Yet High-Precision Adjustment
Smooth and Continuous Content Playback

Showing 3 of 3

Related resources

Brochures

Image Data

Operating Instructions

Connect with Panasonic Visual

Full specifications

Download specifications

Projector type	1-Chip DLP™ projector
DLP™ Chip \| Panel Size	16.5 mm (0.65 in) diagonal (16:9 aspect ratio)
DLP™ chip \| Number of Pixels	2,073,600 (1920 x 1080 pixels)
Light Source	Laser diodes
Light output*1	7,500 lm2 / 7,500 lm (ANSI)3 / 7,700 lm (Center)*4
Time until light output declines to 50 %*5	20,000 hours (NORMAL/QUIET), 24,000 hours (ECO)
Resolution	4K (3840 x 2160 pixels) (Quad Pixel Drive: ON)
Contrast Ratio*2	15,000:1 (Full On/Full Off, Dynamic Contrast [3])
Screen Size (Diagonal)	1.27–5.08 m (50–200 in) with ET-DLE055, 1.27–15.24 m (50–600 in) with ET-DLE060/ET-DLE085/ET-DLE105/ET-DLE150/ET-DLE170/ET-DLE250/ET-DLE350/ ET-DLE450, 2.54–8.89 m (100–350 in) with ET-DLE035, 2.54–10.16 m (100–400 in) with ET-DLE020G/ET-DLE020
Center-to-corner zone ratio*2	90%
Lens	Optional (no lens included with this model)
Lens shift \| Vertical(From the origin point of the lens mounter)	+66 %, -18 % (with ET-DLE150/ET-DLE170/ET-DLE250/ET-DLE350/ET-DLE450); +60 %, -18 % (with ET-DLE085/ET-DLE105); +50 %, -18 % (with ET-DLE060); +55 %, -22 % (with ET-DLE020G/ET-DLE020); +97 % (with ET-DLE035); (powered)
Lens shift \| Horizontal(From the origin point of the lens mounter) *6	+30 %, -10 % (with ET-DLE150/ET-DLE170/ET-DLE250/ET-DLE350/ET-DLE450); +28 %, -10 % (with ET-DLE085/ET-DLE105); +19 %, -10 % (with ET-DLE060); +10 %, -20 % (with ET-DLE020G/ET-DLE020); (powered)
Keystone Correction Range	Vertical: ±45 ° (±5 ° with ET-DLE020G/ET-DLE020, +5 ° with ET-DLE035, ±16 ° with ET-DLE060, ±22 ° with ET-DLE55/ET-DLE085/ET-DLE105, ±40 ° with ET-DLE150/ ET-DLE170/ET-DLE250), Horizontal: ±40 ° (±10 ° with ET-DLE060, ±15 ° with ET-DLE55/ET-DLE085/ET-DLE105, cannot be used with ET-DLE020G/ET-DLE020/ET-DLE035)
Installation	Ceiling/floor, front/rear, free 360-degree installation
Terminals \| Serial In	D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
Terminals \| DIGITAL LINK/LAN	RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net, HDCP 2.3, Deep Color, 4K/60p7, 8 signal input)
Terminals \| LAN	RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible
Terminals \| Serial Out	D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
Terminals \| Expansion Slot	Open slot for function boards, Intel® SDM standard-compatible
Terminals \| HDMI™ IN	HDMI™ x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input*7)
Terminals \| Remote In	M3 stereo mini-jack x 1 for wired remote control
Terminals \| Remote Out	M3 stereo mini-jack x 1 for link control (for wired remote control)
Terminals \| USB(DC OUT)	USB connector (Type A) x 1 for DC 5 V/ 2 A power supply, optional AJ-WM50 Series Wireless Module, and data transfer from USB memory
Protocol versions	IPv4, IPv6*9
Power Supply	AC 100–240 V, 50/60 Hz
Maximum power consumption*10	670 W (6.8–2.8 A) (680 VA) (Power consumption is 650 W at AC 200–240 V)
On-mode power consumption (Operating mode)*10 \| Normal	540 W (AC 100–120 V), 520 W (AC 200–240 V)
On-mode power consumption (Operating mode)*10 \| ECO	410 W (AC 100–120 V), 400 W (AC 200–240 V)
On-mode power consumption (Operating mode)*10 \| QUIET	410 W (AC 100–120 V), 400 W (AC 200–240 V)
Operation Noise*2	35 dB (NORMAL/ECO), 32 dB (QUIET)
Dimensions (W x H x D)	498 x 170 x 440 mm (19 19/32˝ x 6 11/16˝ x 17 5/16˝) (With legs at shortest position, excluding protruding parts)
Operating Environment	Operating temperature: 0–45 °C (32–113 °F)*12, operating humidity: 10–80 % (no condensation)
Applicable Software	Multi Monitoring & Control Software, Projector Network Setup Software, Real-Time Tracking Projection-Mapping System*13, Geometry Manager Pro, Smart Projector Control for iOS/Android™
Control function via LAN	Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2)
Note	1 When ET-DLE170 is attached. When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL]. 2 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped. 3 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped. 4 Average light-output value of all shipped products measured at the center of the screen. 5 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft), with 0.15 mg/m3 of airborne particulate matter. The estimated time until light output declines to 50 % varies depending on the environment. 6 Cannot be used when ET-DLE035 is installed. 7 4K signals are converted to WUXGA (1920 x 1200 pixels) only for the PT-RZ7L/RZ6L. 8 Supports YPBPR 4:2:0 format only for 4K/60p and 4K/50p signals input via DIGITAL LINK. 9 Optional AJ-WM50 Series Wireless Module is not compatible with IPv6. 10 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft). 11 Average value. May dier depending on the actual unit. 12 When the optional AJ-WM50 Series wireless module is attached, the operating temperature range becomes 0–40 °C (32–104 °F). Note that the projector cannot be used at altitudes 4,200 m (13,780 ft) or higher above sea level. In the following operating environments, light output may be reduced to protect the projector: when the projector is used at altitudes below 1,400 m (4,593 ft) and ambient temperature is 35 °C (95 °F) or higher; when the projector is used at altitudes between 1,400 m (4,593 ft) and 2,700 m (8,858 ft) exclusive and ambient temperature is 30 °C (86 °F) or higher; and when the projector is used at altitudes between 2,700 m (8,858 ft) and 4,200 m (13,780 ft) exclusive and ambient temperature is 25 °C (77 °F) or higher. *13 PT-RQ7L/RQ6L only
Weight*11	16.6 kg (36.59 lbs)
