30 000 lumens-class 4K+ Solid Shine Laser Projector
PT-RQ32K
DiscontinuedStunning image quality in a compact body designed for large venues. Laser light source, 3-chip DLP, 27000 centre lumens, 4K+, maintenance-free projector.
Key features
Laser 3-chip DLP, 27000 lumens (centre), 4K+ |
Lamp-free laser projection with dust resistant liquid cooling system for 20000 hours maintenance free operation |
5K pixel performance with a quad pixel drive system on a WQXGA chipset |
240Hz high frame rate for superb and sharp motion pictures |
20,000:1 contrast ratio |
PT-RQ32 | PT-RZ31 | PT-RS30 | |
---|---|---|---|
Brightness | 27.000 lm (center) / 26.000 lm | 31.000 lm (center) / 30.000 lm | 31.000 lm (center) / 30.000 lm |
Resolution | 4K | WUXGA (1,920x 1,200) | SXGA+ (1,400x 1,050) |
Contrast | 20.000:1 | 20.000:1 | 20.000:1 |
- Outstanding durability
- Deliver absolute immersion
- Flexible setup
- Smooth operation
Panasonic brings a new dimension to 4K projection, putting the PT-RQ32 to the top of its large venue projector range. It offers resellers and staging professionals reduced motion blur, multi-projection layout and fast-moving 4k sequences, while reducing overheads and total cost of ownership. Panasonic RQ32 sets a new standard in both detail and clarity so that audiences can enjoy true-to-life detail, bright and vivid colour accuracy and high contrast in large venues.
DURABILITY IN TEMPORARY OR PERMENANT INSTALLATIONS
20,000 hours of service free operation and outstanding durability
Experience the ultimate operability and durability with dustproof protection and a long life filter that provides 20,000 hours of service free operation. The long life filter includes an electrostatic Micro Cut Filter that collects minute dust particles with an ion effect that reduces downtime, and a super-efficient cooling system that enhances reliability.
DELIVER ABSOLUTE IMMERSION
Going above and beyond 4K resolution
Utilising quad pixel drive technology, PT-RQ32 delivers extremely detailed, film-like, 4K image quality that brings true-to-life detail and realism to every audience. It also supports BT.2020 and HDR for the latest 4K standard, rendering more colourful and realistic content.
Smooth and realistic motion rendering
Panasonic’s unique high-speed 240 Hz frame-creation technology for up to 5120 x 3200-pixel (16:10) images ensures audiences can enjoy clearer and sharper playback of fast-moving 4K+ sequences.
Real Motion Processor uses sophisticated algorithms to create three additional frames for each image, boosting native 60 fps footage to 240 frames per second. The result is smooth, lifelike, fluid and realistic motion rendering, particularly useful for broadcasting sporting events and other fast-paced video footage.
Optimised detail reproduction in 4K+ images
The PT-RQ32 uses Panasonic’s new generation circuit technology that analyses each individual image frame by frame to clarify areas containing fine details and textures. Powerful algorithms extract hidden information from the frequency video bands; sharpening outlines, correcting contours, and reducing ringing noise – all of which help to deliver high-impact, precise images.
FLEXIBLE SETUP AND SMOOTH OPERATION
360-degree flexibility
SOLID SHINE Laser technology enables free 360-degree installation through any axis. Courtesy of a powered lens shift and a wide range of optional lenses, the projector can be mounted in any way desired without picture distortion - either temporarily or in permanent applications.
Seamless scene-linking
Digitally controlled frame-by-frame scene-linking delivers consistent picture quality across large screens. This helps to achieve a remarkable 20,000:1 contrast without lowering its high brightness. It also reproduces deeper, richer blacks, and provides images with more detailed textures. Meanwhile, the Shutter Sync function synchronizes shutter on/off timing between all networked projectors.
Single-Cable 4K DIGITAL LINK Connection
Based on HDBaseT™ technology, DIGITAL LINK supports transmission of video, audio1, and control commands through a single CAT 5e or higher STP cable for distances of 150 m (492 ft) for Full HD video and 50 m (164 ft) for 4K2 video. An optional DIGITAL LINK Switcher or Digital Interface Box further simplifies installation in large venues while reducing cost and improving reliability.
*1 Audio transmission depending on model’s audio capability, *2 ET-YFB200G/YFB100G is not compatible with 4K signals. 150 m (492 ft) transmission available only with ET-YFB200G DIGITAL LINK Switcher for signals up to 1080p in Long Reach Mode.
Assuring image display is always maintained
An automatic backup input setting promises uninterrupted image display in venues such as control rooms, and giving added reassurance at events where projection can’t afford to be interrupted.
Sophisticated image-adjustment software
Geometry Manager Pro is free software that offers more sophisticated image-adjustment functionality and makes complex multi-screen setup easy. An optional ET-UK20 upgrade kit with Geometry Manager Pro software supports colour matching, edge blending for multi-projector set ups. It’s flexile and complex geometric adjustment capability suits a wide variety of screen shapes.
Early Warning Software ET-SWA100 Series (Optional)
Early Warning Software monitors the status of projectors and displays connected to an intranet, and notifies the operator when issues are detected or predicted. This helps to minimise downtime and provides stable and continuous operation.
Common Lenses for Panasonic 3-Chip DLP™ Projectors
Panasonic 3-Chip DLP™ projectors share a range of optional lenses, including ultra-short-throw lens and zoom lens for long throw distances, so you can switch and change lenses to suit the venue. This reduces the total cost of ownership for staging and event companies with large projector requirements.
Product gallery
Specifications table
Brightness | 27000 lumens (centre) |
---|---|
Technology | 3-chip DLP Laser |
Resolution | 5120 x3200 pixels when Quad Pixel Drive set to ON |
Brightness*4 | Varies depending on operation mode setting. 26,000 lm*2*4/27,000 lm*3*4 (Center) (HIGH) 21,600 lm*2*4/22,500 lm*3*4 (Center) (NORMAL) 12,000 lm at constant luminance (LONG LIFE 1) 10,000 lm at constant luminance (LONG LIFE 2) 8,000 lm at constant luminance (LONG LIFE 3) |
Light Source | Laser Diode Laser class 1 |
DLP™ Chip | Panel Size | 22.9mm (0.9 inches) diagonal (16:10 aspect ratio) |
DLP™ Chip | Display Method | DLP™ chip x 3 (R, G, B), DLP™ projection system |
DLP™ Chip | Pixels | 4,096,000 (2560 x1600) x3, total of 12,288,000 pixels |
Product series
PT-RZ31K Series
PT-RZ31K Series | |||
---|---|---|---|
Model | |||
Lens test | Optional powered zoom/focus lenses | Optional powered zoom/focus lenses | Optional powered zoom/focus lenses. |
DLP™ Chip | Panel Size | 24.4 mm (0.96 inches) diagonal (16:10 aspect ratio) | 24.1 mm (0.95 inches) diagonal (4:3 aspect ratio) | 22.9mm (0.9 inches) diagonal (16:10 aspect ratio) |
DLP™ Chip | Display Method | DLP™chip x 3 (R, G, B), DLP™projection system | DLP™chip x 3 (R, G, B), DLP™projection system | DLP™ chip x 3 (R, G, B), DLP™ projection system |
DLP™ chip | Number of Pixels | 2,304,000 (1920 x1200) x3, total of 6,912,000 pixels | 1,470,000 (1400 x1050) x3, total of 4,410,000 pixels | 4,096,000 (2560 x1600) x3, total of 12,288,000 pixels |
Brightness | Varies depending on operation mode setting.
30,000 lm*2*4/31,000 lm*3*4 (Center) (HIGH)
25,000 lm*2*4/26,000 lm*3*4 (Center) (NORMAL)
12,000 lm at constant luminance (LONG LIFE 1)
10,000 lm at constant luminance (LONG LIFE 2)
8,000 lm at constant luminance (LONG LIFE 3) | 30,000 lm/ 31,000 lm (Center) | Varies depending on operation mode setting.
26,000 lm*2*4/27,000 lm*3*4 (Center) (HIGH)
21,600 lm*2*4/22,500 lm*3*4 (Center) (NORMAL)
12,000 lm at constant luminance (LONG LIFE 1)
10,000 lm at constant luminance (LONG LIFE 2)
8,000 lm at constant luminance (LONG LIFE 3) |
Light Source | Laser Diode Laser class 1 | Laser Diode Laser class 1 | Laser Diode Laser class 1 |
Resolution | 1920 x1200 pixels (Input signals that exceed this resolution will be
converted to 1920 x1200 pixels.) | 1400 x1050 pixels (Input signals that exceed this resolution will be
converted to 1400 x1050 pixels.) | 5120 x3200 pixels when Quad Pixel Drive set to ON |
Contrast Ratio | 20,000:1 (full on/full off, in Dynamic Contrast 3 mode) | 20,000:1 (full on/full off, in Dynamic Contrast 3 mode) | 20,000:1 (full on/full off, in Dynamic Contrast 3 mode) |
Screen Size | 1.78-25.4 m (70-1,000 inches) (16:10 aspect ratio)
1.78-15.24 m (70-600 inches) with the ET-D75LE8 (16:10 aspect ratio)
3.05-15.24 m (120 - 600 inches) with the ET-D75LE95 (16:10 aspect ratio) | 1.78-25.4 m (70-1,000 inches) (4:3 aspect ratio)
1.78-15.24 m (70-600 inches) with the ET-D75LE8 (4:3 aspect ratio)
3.05-15.24 m (120-600 inches) with the ET-D75LE95 (4:3 aspect ratio) | 1.78-25.4 m (70-1,000 inches) (16:10 aspect ratio)
1.78-15.24 m (70-600 inches) with the ET-D75LE8 (16:10 aspect ratio)
3.05-15.24 m (120 - 600 inches) with the ET-D75LE95 (16:10 aspect ratio) |
Optical Axis Shift | Vertical | ±55% (±44% with the ET-D75LE6), (+68-78% with the ET-D75LE95),
from center of screen, powered | ±50% (±40% with the ET-D75LE6), (+67-71% with the ET-D75LE95),
from center of screen, powered | ±59% (±56% with the ET-D75LE6), (+69-84% with the ET-D75LE95), from center of screen, powered |
Optical Axis Shift | Horizontal | ±20% (±15% with the ET-D75LE6), (±12% with the ET-D75LE95),
from center of screen, powered
NOTE: Optical axis shift function cannot be operated when used with the ET-D75LE50. | ±30% (±20% with the ET-D75LE6), (±8% with the ET-D75LE95),
from center of screen, powered
NOTE: Optical axis shift function cannot be operated when used with the ET-D75LE50. | ±29% (±19% with the ET-D75LE6), (±21% with the ET-D75LE95), from center of screen, powered
NOTE: Optical axis shift function cannot be operated when used with the ET-D75LE50. |
Lens | Optional powered zoom/focus lenses | Optional powered zoom/focus lenses | Optional powered zoom/focus lenses. |
Installation | Ceiling/floor, front /rear, free 360-degree installation | Ceiling/floor, front /rear, free 360-degree installation | Ceiling/floor, front /rear, free 360-degree installation |
Terminals | SDI In 1 | BNC x 1
SD-SDI signal SMPTE ST 259 compliant
HD-SDI signal SMPTE ST 292 compliant
3G-SDI signal SMPTE ST 424 compliant
Dual link HD-SDI (LINK-A) signal SMPTE ST 372 compliant
Dual link 3G-SDI (Link 1) signal SMPTE ST 425 compliant | BNC x 1
SD-SDI signal SMPTE ST 259 compliant
HD-SDI signal SMPTE ST 292 compliant
3G-SDI signal SMPTE ST 424 compliant
Dual link HD-SDI (LINK-A) signal SMPTE ST 372 compliant
Dual link 3G-SDI (Link 1) signal SMPTE ST 425 compliant | BNC x 1
SD-SDI signal SMPTE ST 259 compliant
HD-SDI signal SMPTE ST 292 compliant
3G-SDI signal SMPTE ST 424 compliant
Dual link HD-SDI (LINK-A) signal SMPTE ST 372 compliant
Dual link 3G-SDI (Link 1) signal SMPTE ST 425 compliant
Quad-link HD-SDI (Link 1) signal
Quad-link 3G-SDI (Link 1) signal SMPTE ST 425 compliant |
Terminals | HDMI In | HDMI 19-pin x1
HDCP compatible, Deep Color compatible | HDMI 19-pin x1
HDCP compatible, Deep Color compatible | |
Terminals | DVI-D In | DVI-D 24-pin x1
Single link, DVI 1.0 compliant, HDCP compatible | DVI-D 24-pin x1
Single link, DVI 1.0 compliant, HDCP compatible | |
Terminals | RGB 1 In | BNC x 5 | BNC x 5 | |
Terminals | RGB 1 In | R, G, B | R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic | R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic | |
Terminals | RGB 1 In | Y, PB, PR (Y, CB, CR) | Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms | Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms | |
Terminals | RGB 1 In | Video in | BNC x 1, 1.0 Vp-p, 75 ohms | BNC x 1, 1.0 Vp-p, 75 ohms | |
Terminals | RGB 2 In | D-sub HD 15-pin (female) x 1 | D-sub HD 15-pin (female) x 1 | |
Terminals | RGB 2 In | R, G, B | R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic | R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic | |
Terminals | RGB 2 In | Y, PB, PR (Y, CB, CR) | Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms | Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms | |
Terminals | Multi Projector Sync In | BNC x 1, IN : TTL Hi-z | ||
Terminals | Multi Projector Sync Out | BNC x 1, TTL max10mA | ||
Terminals | Serial In | D-sub 9 pin x 1 for external control (RS-232C compliant) | D-sub 9 pin x 1 for external control (RS-232C compliant) | D-sub 9 pin x 1 for external control (RS-232C compliant) |
Terminals | Serial Out | D-sub 9 pin x 1 for link control | D-sub 9 pin x 1 for link control | D-sub 9 pin x 1 for link control (RS-232C compliant) |
Terminals | Remote 1 In | M3 stereo mini jack x 1 for wired remote control | M3 stereo mini jack x 1 for wired remote control | M3 stereo mini jack x 1 for wired remote control |
Terminals | Remote 1 Out | M3 stereo mini jack x 1 for link control | M3 stereo mini jack x 1 for link control | M3 stereo mini jack x 1 for link control |
Terminals | Remote 2 In | D-sub 9 pin x 1 for external control (parallel) | D-sub 9 pin x 1 for external control (parallel) | D-sub 9 pin x 1 for external control (parallel) |
Terminals | DIGITAL LINK | RJ-45 x 1 (for network, DIGITAL LINK connection, 100Base-TX,
compatible with Art-Net, PJLink™ (class 1), Deep Color, HDCP) | RJ-45 x 1 (for network, DIGITAL LINK connection, 100Base-TX,
compatible with Art-Net, PJLink™ (class 1), Deep Color, HDCP) | RJ-45 x 1 (for network, DIGITAL LINK connection, 100Base-TX,compatible with Art-Net, PJLink? (class 1), Deep Color, HDCP) |
Terminals | DC Out | USB connector (type A) x 2 for power supply only (DC 5V, Max.900mA) | USB connector (type A) x 2 for power supply only (DC 5V, Max.900mA) | USB connector (type A) x 2 for power supply only (DC 5V, Max.900mA) |
Terminals | Expansion Slot | x 2 (SLOT 1, SLOT 2), SLOT NX(Compatible with Optional Board) | ||
Power Supply | AC 100-120 V, 50/60 Hz; AC 200-240 V, 50/60 Hz | AC 100-120 V, 50/60 Hz; AC 200-240 V, 50/60 Hz | 100 V - 120 V / 200 V - 240 V - (100 V - 120 V / 200 V - 240 V alternating current), 50 Hz/60 Hz (PT-RQ32K)
200 V - 240 V - (200 V - 240 V alternating current) |
Power Consumption | 2,870 W (2,870 VA AC200V)
Average power consumption
(Varies depending on operation mode setting.)
HIGH: 2,310W NORMAL: 1,890W
LONG LIFE 1: 1,040-1,680W
LONG LIFE 2: 924-1,580W
LONG LIFE 3: 794-1,460W
*Operating Temperature: 25 °C (77 °F),
Altitude: 700m (2,297ft), IEC627087: 2008 Broadcast contents,
Picture mode: Standard, Dynamic contrast [2]
0.3 W with STANDBY MODE set to ECO
4 W with STANDBY MODE set to NORMAL | 2,870 W (2,870 VA AC200V)
Average power consumption
Varies depending on operation mode setting.)
HIGH: 2,310W NORMAL: 1,890W
LONG LIFE 1: 1,040-1,680W
LONG LIFE 2: 924-1,580W
LONG LIFE 3: 794-1,460W
*Operating Temperature: 25 °C (77 °F),
Altitude: 700m (2,297ft), IEC627087: 2008 Broadcast contents,
Picture mode: Standard, Dynamic contrast [2]
0.3 W with STANDBY MODE set to ECO
4 W with STANDBY MODE set to NORMAL | 50 Hz/60 Hz (PT-RQ32KD)
2,950 W (12 A/16 A) (PT-RQ32K)
2,950 W (16.1 A) (PT-RQ32KD)
Average power consumption
Varies depending on operation mode setting.)
HIGH: 2,400W NORMAL: 2,000W
LONG LIFE 1: 1,190-1,780W
LONG LIFE 2: 1,060-1,700W
LONG LIFE 3: 926-1,580W
*Operating Temperature: 25,
Altitude: 700m (2,297ft), IEC627087: 2008 Broadcast contents,
Picture mode: Standard, Dynamic contrast [2]
0.3 W with STANDBY MODE set to ECO*1
4 W with STANDBY MODE set to NORMAL |
Cabinet Materials | Processed metal parts, Molded plastic | Processed metal parts, Molded plastic | Processed metal parts, Molded plastic |
Operating Temperature | Varies depending on operation mode setting.
HIGH/NORMAL
The operating temperature range is 0°C to 50°C (32 °F to 122 °F).
(Less than 1,400m (4,593 ft) above sea level)
The operating temperature range is 0°C to 45°C (32 °F to 113 °F).
(Less than 1,400m (4,593 ft) to 4,200m (13,780 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher and at
less than 2,700m (8,858 ft) above sea level, or at ambient operating
temperatures of 25 °C (77 °F) or higher and between 2,700m (8,858 ft) and
4,200m (13,780 ft) above sea level, the brightness of the light source may
drop in order to protect the projector.
LONG LIFE 1/2/3
The operating temperature range is 0°C to 45°C (32 °F to 113 °F).
(Less than 2,700m (8,858 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher,
the brightness of the light source may drop in order to protect the projector.
When using a smoke cut
lter (regardless of operating mode)
0 °C to 40 °C (32 °F to 104 °F) Less than 1,400 m (4,953 ft) above sea level | Varies depending on operation mode setting.
HIGH/NORMAL
The operating temperature range is 0°C to 50°C (32 °F to 122 °F).
(Less than 1,400m (4,593 ft) above sea level)
The operating temperature range is 0°C to 45°C (32 °F to 113 °F).
(Less than 1,400m (4,593 ft) to 4,200m (13,780 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher and at
less than 2,700m (8,858 ft) above sea level, or at ambient operating
temperatures of 25 °C (77 °F) or higher and between 2,700m (8,858 ft) and
4,200m (13,780 ft) above sea level, the brightness of the light source may
drop in order to protect the projector.
LONG LIFE 1/2/3
The operating temperature range is 0°C to 45°C (32 °F to 113 °F).
(Less than 2,700m (8,858 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher,
the brightness of the light source may drop in order to protect the projector.
When using a smoke cut
lter (regardless of operating mode)
0 °C to 40 °C (32 °F to 104 °F) Less than 1,400 m (4,953 ft) above sea level | Varies depending on operation mode setting.
HIGH/NORMAL
The operating temperature range is 0°C to 45°C (32 °F to 113 °F).
(Less than 1,400m (4,593 ft) above sea level)
The operating temperature range is 0°C to 40°C (32 °F to 104 °F).
(Less than 1,400m (4,593 ft) to 4,200m (13,780 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher and at
less than 2,700m (8,858 ft) above sea level, or at ambient operating
temperatures of 25 °C (77 °F) or higher and between 2,700m (8,858 ft) and
4,200m (13,780 ft) above sea level, the brightness of the light source may
drop in order to protect the projector.
LONG LIFE 1/2/3
The operating temperature range is 0°C to 40°C (32 °F to 104 °F).
(Less than 2,700m (8,858 ft) above sea level)
• If using at ambient operating temperatures of 35 °C (95 °F) or higher,
the brightness of the light source may drop in order to protect the projector.
When using a smoke cut
lter (regardless of operating mode)
0 °C to 40 °C (32 °F to 104 °F) Less than 1,400 m (4,953 ft) above sea level |
Dimensions | 700 x 418*8x1,250 mm
(27-9/16 x 16-15/32 x 49-7/32 inches) (with protrusion parts)
700 x 373*9x1,070 mm
(27-9/16 x 14-11/16 x 42-1/8 inches) (without protrusion parts) | 700 x 418*8x1,250 mm
(27-9/16 x 16-15/32 x 49-7/32 inches) (with protrusion parts)
700 x 373*9x1,070 mm
(27-9/16 x 14-11/16 x 42-1/8 inches) (without protrusion parts) | 700 x 418*6x1,250 mm
(27-9/16 x 16-15/32 x 49-7/32 inches) (with protrusion parts)
700 x 373*7x1,070 mm
(27-9/16 x 14-11/16 x 42-1/8 inches) (without protrusion parts) |
Weight | 79 kg (174.2 lbs) | 79 kg (174.2 lbs) | 83 kg (183 lbs) |
Accessories & Software
Lenses for 3-Chip DLP < 35.000 lumens
ET-D3LEU101
Deliver Spectacular Images at Short Distance with New Zero-Offset Lenses
Lenses for 3-Chip DLP < 35.000 lumens
ET-D3LEW201
Deliver Spectacular Images at Short Distance with New Zero-Offset Lenses
Lenses for 3-Chip DLP < 35.000 lumens
ET-D3LEF70
Fisheye lens for 3-Chip DLP projectors perfect for dome and planetarium projection
Showing 3 of 3
Interface board/conversion cable
ET-MDNDV10
DVI-D input signal board
Interface board/conversion cable
TY-TBN03G
3G-SDI input signal board
Interface board/conversion cable
ET-MDN12G10
12G-SDI signal board
Showing 3 of 3
Filters
ET-EMFU330
The Replacement Long-life filter is designed for compatibility with PT-RZ31, PT-RS30, PT-RQ32 projectors.
Showing 1 of 1
Related resources
Showing 12 of 94
Showing 12 of 18
Showing 12 of 17
Sorry there was an error...
The files you selected could not be downloaded as they do not exist.
You selected items.
Continue to select additional items or download selected items together as a zip file.
You selected 1 item.
Continue to select additional items or download the selected item directly.
Share page
Share this link via:
Twitter
LinkedIn
Xing
Facebook
Or copy link:
