PT-EX620/EX620L

Discontinued

Diseñado para iluminar salas de discursos y conferencias. LCD, 6200 lúmenes, proyector XGA

6.200 lm LCD XGA

View specifications Inicio

Key features of PT-EX620/EX620L

Características principales

LCD, 6200 lúmenes, XGA

Alto brillo y en un cuerpo compacto y ligero

Cuerpo resistente al polvo y hasta 15.000 horas sin mantenimiento Eco Filter

Desplazamiento motorizado del objetivo y una amplia gama de objetivos opcionales

Relación de contraste de 10.000:1 (en modo de alto contraste)

Excelente calidad de imagen

Alto brillo de hasta 6.200 lm en una carcasa compacta
Contraste dinámico de 10.000:1 con iris
Alta resolución hasta XGAque permite obtener imágenes Full HD de gran detalle
La función Daylight View Basic garantiza imágenes nítidas y definidas en entornos brillantes
Modo de simulación DICOM^*1 para presentaciones médicas
Función de ajuste cromático para corregir las variaciones de color en aplicaciones multiproyector

MÁS INFORMACIÓN

Specifications of PT-EX620/EX620L

Tabla de especificaciones

Projector type	LCD projector
Display method	Transparent LCD panel (x 3, R/G/B)
Display Device -> Panel size	16.0 mm (0.63˝) diagonal (4:3 aspect ratio)
Display Device -> Drive method	Active matrix method
Display Device -> Number of pixels	786,432 (1024 x 768) x 3, total of 2,359,296 pixels
Light output^*1	6,200 lm
Light output (ANSI)	6,200 lm
Lamp	320 W UHM lamp x 1

View specifications Download specifications

Accesorios y software

ET-LAEF100

ET-LAEF100. .

Ver producto

Solicitar presupuesto

Showing 1 of 1

ET-PKD120H

Soporte de montaje para techos altos

Ver producto

Solicitar presupuesto

ET-PKD120S

Soporte de montaje para techos bajos

Ver producto

Solicitar presupuesto

ET-PKE301B

Conjunto de abrazadera

Ver producto

Solicitar presupuesto

Showing 3 of 3

ET-RFE300

Filtro ecológico

Ver producto

Solicitar presupuesto

Showing 1 of 1

ET-FMP20

Los procesadores multimedia redefinen los flujos de trabajo en experiencias inmersivas con multiproyección.

Ver producto

Solicitar presupuesto

Showing 1 of 1

ET-FMP20

Los procesadores multimedia redefinen los flujos de trabajo en experiencias inmersivas con multiproyección.

Ver producto

Solicitar presupuesto

Showing 1 of 1

LIMITED STOCKS

ET-WML100

Módulo inalámbrico

Ver producto

Solicitar presupuesto

Showing 1 of 1

PressIT - Sistema de Presentación Inalámbrico

Compatible con LAN inalámbrica de 6 GHz. Sistema de presentación inalámbrico "PressIT" con visualización de vídeo de alta calidad y flexibilidad de instalación mejorada - Basta con conectar el transmisor y visualizar imágenes 4K en la pantalla con solo pulsar un botón.

Ver producto

Solicitar presupuesto

Showing 1 of 1

ET-ADSV

Cable de conversión de D-Sub/S-VIDEO

Ver producto

Solicitar presupuesto

Showing 1 of 1

Aviso conforme a la Ley de Datos de la UE sobre los datos generados por nuestros productos.

Conéctese con Panasonic Visual

Full specifications

Download specifications

Projector type	LCD projector
Display method	Transparent LCD panel (x 3, R/G/B)
Display Device -> Panel size	16.0 mm (0.63˝) diagonal (4:3 aspect ratio)
Display Device -> Drive method	Active matrix method
Display Device -> Number of pixels	786,432 (1024 x 768) x 3, total of 2,359,296 pixels
Light output^*1	6,200 lm
Light output (ANSI)	6,200 lm
Lamp	320 W UHM lamp x 1
Lamp replacement cycle -> NORMAL	4,000 hours
Lamp replacement cycle -> ECO	5,000 hours *2
Brightness	6,200 lm (Lamp Power: Normal, Dynamic Mode, Iris: OFF, Daylight View: OFF, Auto Power Save: OFF)
Resolution	1024 x 768 pixels*4
Contrast Ratio (typ.)^*1	10,000:1 (Lamp Power: Normal, Dynamic Mode, Iris: ON, Daylight View: OFF, Auto Power Save: OFF)
Screen size (diagonal)	1.05–10.77 m (40–400˝), 4:3 aspect ratio
Lens	PT-EX620:1.8 x powered zoom (throw ratio 1.32–2.44:1), powered focus F 1.6–2.2, f 17.1–31.7 mm PT-EX620L:Optional powered zoom/focus lenses and fixed-focus lens
Lens shift -> Vertical(from center of screen)　^*4	±50 % (powered)
Lens shift -> Horizontal(from center of screen)　^*4	±30 % (powered)
Keystone correction range	Vertical: ±25 °, horizontal: ±30 °
Installation	Ceiling/floor, front/rear
Power supply	100–240 V AC, 50/60 Hz
Maximum power consumption	461 W (0.5 W with Standby Mode set to Eco*1, 8 W with Standby Mode set to Normal); 424 W with Lamp Power set to OFF, 305 W with Lamp Power set to Eco
Standby power consumption -> Normal	8W
Standby power consumption -> ECO	0.5W
Power consumption	461 W (0.5 W with Standby Mode set to ECO, 8 W with Standby Mode set to Normal); 424 W with Lamp Power set to OFF, 305 W with Lamp Power set to Eco
Cabinet materials	Molded plastic (PC + ABS)
Filter	Included
Operation noise -> Normal^*1	35 dB [NORMAL]
Operation noise -> Eco^*3	29 dB [ECO]
Dimensions (W x H x D)	PT-EX620 : 498 x 1456 x 398.3 mm (19 19/32˝ x 5 11/16˝6 x 15 11/16˝) (with supplied lens)PT-EX620L : 498 x 1456 x 358 mm (19 19/32˝ x 5 11/16˝6 x 14 3/32˝) (with supplied lens)
Dimensions -> Width (including protruding parts)	498 mm (19 19/32˝)
Dimensions -> Height (including protruding parts)	145 mm (5 11/16˝)
Dimensions -> Depth (not including protruding parts)	PT-EX620:398.3 mm (15 11/16˝)PT-EX620L:358 mm (14 3/32˝)
Weight [kg]^*7	PT-EX620:Approx. 8.4 kg (18.5 lbs) (with supplied lens)PT-EX620L:Approx. 7.7 kg (17.0 lbs) (without lens)
Operating environment -> Operating temperature^8^9	0–45 °C (32–113 °F)
Operating Environment -> Operating humidity (No condensation)	20–80 % (no condensation)
Applicable software	Logo Transfer Software, Multi Monitoring Control Software, Early Warning Software
Body Colour	White
Gross Dimensions (W x H x D in mm)	EX620U/EX620EJ/EX620LU/EX620LEJ: 657 x 558 x 311 mm EX620E/EX620A/EX620LE/EX620LA: 644 x 545 x 288 mm
Gross Weight (Kg)	EX620EJ: 13.8 kg(30.4 lbs) EX620U: 13.4 kg(29.5 lbs) EX620LEJ: 13.1 kg(28.8 lbs) EX620LU: 12.7 kg(28.0 lbs) EX620E: 12.5 kg(27.5 lbs) EX620A: 12.1 kg(26.6 lbs) EX620LE: 11.8 kg(25.9 lbs) EX620LA: 11.4 kg(25.1 lbs)
NFC	https://docs.connect.panasonic.com/projector/products/smartpjcontrol/regional.html#regional
EAN	EX620E: 5025232838721 EX620EJ: 5025232838738 EX620A: 5025232838752 EX620LE: 5025232838783 EX620LEJ: 5025232838790 EX620LA: 5025232838813
Descripción de la nota al pie	When Standby Mode is set to Eco, network functions such as power on over LAN will not operate. Also, only certain commands can be received for external control using the serial terminal. This is the maximum value when the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more frequently or kept on for a long time, lamp replacement cycle will be reduced. Usage environment affects the duration of the lamp. Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards. Input signals that exceed supported resolution will be converted. With the supplied lens. Value differs when the correction for both directions is operated. With legs at shortest position. Average value. May differ depending on models. At altitudes below 1,400 m (4.593 ft) above sea level. Operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when used at altitudes from 1,400 m to 2,700 m (4,593 ft to 8,858 ft) above sea level. Also, if ambient temperature exceeds 40 °C (104 °F) (35 °C [95 °F] at high altitude), lamp power automatically switches to Eco to in order to protect the projector.
