| General -> Power Supply | DC 12 V (when using an external power supply)
AC 240 V, 50 Hz/60 Hz (when connecting to an AK-UCU600PJ/AK-UCU600EJ/AK-UCU600PSJ/AK-UCU600ESJ) |
|---|
| General -> Power Consumption | 119 W (maximum for the camera only, when connecting to an external 12 V)
360 W (when connecting to an AK-UCU600PJ/AK-UCU600EJ/AK-UCU600PSJ/AK-UCU600ESJ) |
|---|
| General -> Operating Temperature | -10 °C to 45 °C (14 °F to 113 °F)
(Preheating required under a temperature 0 °C (32 °F) or below) |
|---|
| General -> Operating Humidity | 85 % or less (relative humidity) |
|---|
| General -> Storage Temperature | -20 ℃to 60 ℃ (-4 °F to 140 °F) |
|---|
| General -> Weight | Approx. 4.5 kg (9.90 lb) (body only) |
|---|
| General -> Dimensions | W 151 mm x H 267 mm x D 371.5 mm
(5-31/32 inches x 10-17/32 inches x 14-21/32 inches)
(excluding protrusions) |
|---|
| Camera Unit -> Pickup Device | 11.14 megapixel, MOS x 1 |
|---|
| Camera Unit -> Optical Filter -> CC | 3200 K, 4300 K, 6300 K, Cross, Diffusion |
|---|
| Camera Unit -> Optical Filter -> ND | CAP, Clear, 1/4, 1/16, 1/64 |
|---|
| Camera Unit -> Lens Mount | 2/3-type bayonet |
|---|
| Camera Unit -> Sensitivity | Two shooting modes. 2000 lx, 3200 K, when white reflectivity is 89.9%
[HIGH SENS] F10 (59.94 Hz) / F11 (50 Hz)
[NORMAL] F6 (59.94 Hz) / F7 (50 Hz) |
|---|
| Camera Unit -> Horizontal Resolution -> 4K | 2000 TV lines or above (center, AK-UCU600PJ/AK-UCU600EJ/AK-UCU600PSJ/AK-UCU600ESJ output) |
|---|
| Camera Unit -> Horizontal Resolution -> HD | 1000 TV lines or above (center) |
|---|
| Camera Unit -> S/N | 62 dB or above |
|---|
| Camera Unit -> Horizontal Modulation | 50 % or above (27.5 MHz) |
|---|
| Camera Unit -> Gain Switching -> HIGH SENS | -6, -3, 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33, 36 |
|---|
| Camera Unit -> Gain Switching -> NORMAL | -6, -3, 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33, 36 |
|---|
| Camera Unit -> Shutter Speed -> [59.94i]/[59.94p] mode | 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/1500, 1/2000 |
|---|
| Camera Unit -> Shutter Speed -> [50i]/[50p] mode | 1/60, 1/100, 1/125, 1/250, 1/500, 1/1000, 1/1500, 1/2000 |
|---|
| Camera Unit -> Shutter Speed -> [29.97p] mode | 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/1500, 1/2000 |
|---|
| Camera Unit -> Shutter Speed -> [25p] mode | 1/48, 1/50, 1/60, 1/96, 1/100, 1/125, 1/250, 1/500, 1/1000, 1/1500, 1/2000 |
|---|
| Camera Unit -> Shutter Speed -> [23.98p] mode | 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/1500, 1/2000 |
|---|
| Camera Unit | 2160/59.94p, 50p, 29.97p, 25p, 23.98p,
1080/59.94p, 59.94p-120/180/240 fps, 50p, 50p-100/150/200 fps, 29.97p, 25p, 23.98p |
|---|
| Video Input/Output - > < HD-SDI1 > Terminal | BNC x 1
3G/1.5G-SDI: 0.8 V [p-p], 75 Ω |
|---|
| Video Input/Output - > < HD-SDI2 > Terminal | BNC x 1
3G/1.5G-SDI: 0.8 V [p-p], 75 Ω |
|---|
| Video Input/Output - > < AUX > Terminal | BNC x 1
Functions as terminal/ terminal by switchingthe setting in the menu
: 1.5G-SDI: 0.8 V [p-p], 75Ω
: VBS signal 1 V [p-p], 75 Ω |
|---|
| Video Input/Output - > < G/L IN/PROMPTER OUT > Terminal | BNC x 1
: Tri-level SYNC or BB (black burst)
: VBS signal 1 V [p-p], 75 Ω
Functions as when standalone, and as when connecting to an
AK-UCU600PJ/AK-UCU600EJ/AK-UCU600PSJ/AK-UCU600ESJ |
|---|
| Audio Input/Output - > < MIC 1 > Terminal | XLR x 1, 3-pin (female)
// switchable
For , / switchable
: 0 dBu, +4 dBu menu selection available
: -60 dBu, -40 dBu, or -20 dBu menu can be selected |
|---|
| Audio Input/Output - > < MIC 2 > Terminal | XLR x 1, 3-pin (female)
// switchable
: 0 dBu, +4 dBu menu selection available
: -60 dBu, -40 dBu, or -20 dBu menu can be selected |
|---|
| Audio Input/Output - > < MIC > Terminal (front) | XLR x 1, 3-pin (female)
Switchable with terminal |
|---|
| Intercom - > < INTERCOM1 > Terminal | XLR x 1, 5-pin (female) |
|---|
| Intercom - > < INTERCOM2 > Terminal | XLR x 1, 5-pin (female) |
|---|
| Intercom - > < EARPHONE > Terminal | Stereo mini jack x 1 |
|---|
| Other Input/Output - > < OPT FIBER > Terminal | Optical composite connector x 1, Tajimi/LEMO |
|---|
| Other Input/Output - > < LENS > Terminal | 12-pin x 1 |
|---|
| Other Input/Output - > < VF > Terminal | 20-pin x 1 |
|---|
| Other Input/Output - > < VF > Terminal (rear) | 29-pin x 1 |
|---|
| Other Input/Output - > < DC IN > Terminal | XLR x 1, 4-pin, DC 12 V |
|---|
| Other Input/Output - > < RET CTRL > Terminal | 6-pin x 1 |
|---|
| Other Input/Output - > < EXT I/O > Terminal | 20-pin x 1, DC 12 V 0.5 A |
|---|
| Other Input/Output - > < REMOTE > Terminal | 10-pin x 1 |
|---|
| Other Input/Output - > < TRUNK > Terminal | 12-pin x 1 |
|---|
| Other Input/Output -> ＜DC OUT 12V 2.5A＞ Terminal | 2-pin x 1, DC 12 V 2.5 A |
|---|
| Other Input/Output -> 〈DC OUT 12 V 1 A〉 Terminal | 4-pin x 1 |
|---|
| Other Input/Output - > < LAN > Terminal | RJ-45 x 1 |
|---|
| Other Input/Output - > < USB2.0 > Terminal (host) | Type A connector, DC 5 V 0.5 A |
|---|
| Other Input/Output -> Build-up Terminal | 20-pin x 1 |
|---|
