1-Chip DLP™ Projector PT-REQ15

PT-REQ15

AVAILABLE FROM CY2024 Q2

1-Chip DLP™ Projectors Evolve with 15,000 lm on AC 100–240 V, Unlocking Ideas for Novel Experiences

Scroll down

Key features

Spectacular Visuals on a Grand Scale
Effortless Workflow and Expanded Capabilities
Supremely Reliable Maintenance-Free Operation
PROJECTOR TYPE
MODELSPT-REQ15 *PT-REZ15 *
RESOLUTION4K (3840 x 2400)6WUXGA (1920 x 1200)
BRIGHTNESS15,000 lm115,000 lm1

Product availability and release date may vary by country or region. Please contact a sales representative in your region for details.

Spectacular Visuals on a Grand Scale

Quad Pixel Drive2 creates smooth 4K images, displays 2K/240 Hz3 content without blur, and works with our ET-SWR10 Real-time Tracking Projection-Mapping System7. Rich Color Enhancer ensures accurate red for artwork, while Evolved Dynamic Contrast boosts image realism dramatically. Black-level settings offer precision point-based border adjustment for arbitrary screen shapes.

Effortless Workflow and Expanded Capabilities

REQ15 expands functionality, interfaces, and options for a smoother workflow. It suits new optional lenses featuring powered center and periphery focus8 and has an Intel® SDM-ready slot. The optimized optical engine enables projection at 15,000 lm1 on AC 100–240 V power for efficient installation without needing electrical construction. Other highlights include user test-pattern registration9, NFC function10 for setup prep without AC power, and preactivated upgrade kits for Geo Pro11.

Supremely Reliable Maintenance-Free Operation

Both models feature an optical engine and laser light source module compliant with the IP5X Dust Protected (IEC 60529) standard12 and a refined liquid cooling system. This technology enables up to 20,000 hours13 of continuous maintenance-free projection. Backup Input14 and Multi Laser Drive Engine further enhance reliability and add insurance against interruptions.

1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.
2 PT-REQ15 only.
3 PT-REQ15 only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate.
4 Only when the optional TY-SB01DL DIGITAL LINK Terminal Board is loaded.
5 Input signals to the PT-REZ15 are converted to the projector’s display resolution upon playback. YPBPR 4:2:0 format only for 4K/60p signals input via DIGITAL LINK.
6 Maximum physical resolution with Quad Pixel Drive [ON].
7 Optional ET-SWR10 is used in conjunction with third-party devices (sold separately). Compatibility with third-party devices cannot be guaranteed. Other conditions apply.
8 Lens release date varies depending on the model. Powered periphery focus adjustment is not supported on the ET-C1S600 and ET-C1T700 lenses.
9 Supports PNG (1/8/16/24/32/48/64-bit, non-transparent, alpha blending disabled) and BMP (1/8/24-bit) formats with a maximum resolution of 3840 x 2400 dots (PT-REQ15) or 1920 x 1200 dots (PT-REZ15).
10 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit available from PASS to activate the NFC function.
11 Visit PASS to register your projector and download free Geometry Manager Pro software for Windows® (upgrade kits included).
12 The dust-proof performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.
13 Around this time, the light output will have decreased by approximately 50 %. IEC62087:2008 Broadcast Contents, NORMAL Mode, Dynamic Contrast [3], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.
14 Terminal assignment is fixed. Input signals to primary and backup inputs must be identical.

Specifications table

Projector type1-Chip DLP™ projectors
DLP™ Chip | Panel Size0.8 in diagonal (16:10 aspect ratio)
DLP™ chip | Number of Pixels2,304,000 (1920 x 1200 pixels)
Light SourceLaser Diode
Light Output*1 *215,000lm
Screen size [diagonal]70–700 inches (with supplied lens)
Resolution4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)
Contrast Ratio*125,000:1 (Full On/Full O, Dynamic Contrast [3])
Time until light output declines to 50 %*420,000 hours (NORMAL/QUIET), 24,000 hours (ECO)
LensPowered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus (optional lenses also available)
